Slimline Intrinsically Safe Enclosure
Computer and Screen Protection for ATEX Zone 2 Explosive Areas
Armagard's slim line intrinsically safe computer enclosure is an alternative to air-purged systems and allows the use of conventional computers and TFT flat screens (LCD/Plasma up to 21") in potentially explosive atmospheres (ATEX zone 2/zone 22).
Click thumbnails for larger images:
- Explosion Risk Areas
- Chemical Facilities
- Gas Facilities
- Factory Floors
Intrinsically Safe Enclosure ideal for:
- Size (HxWxD)mm:
- 800 x 600 x 550
- Material:
- Stainless Steel
- Screen Size:
- up to 21"
- Keyboard/mouse:
- Integrated
- Mounting:
- Surface or Stand
- IP rating:
- IP65
- Product Code:
- AZ2S21-TFT-UK
At a glance:
Waterproof and dustproof to IP65 and manufactured from food grade stainless steel (316) this slim line intrinsically safe and airtight enclosure is Ex approved (category 3) in compliance with the European standard for type N restricted breathing devices and the ATEX directive 94/9/EC.
Features & Benefits
Waterproof and dustproof to IP65 and manufactured from food grade stainless steel (316) this slim line intrinsically safe and airtight enclosure is Ex approved (category 3) in compliance with the European standard for type N restricted breathing devices and the ATEX directive 94/9/EC.
| Feature | Benefit |
|---|---|
| Positive Internal Pressure | Prevents potentially explosive gas or dust from re-entering the enclosure eliminating the risk of fire or explosion resulting from ignition by the enclosed computer hardware |
| Manufactured from food grade (316) stainless steel | 316 stainless steel has a high resistance to corrosion and staining. It is low maintenance, and also has antibacterial properties. Ideal for wet or humid conditions or in food preparation areas |
| Membrane Keyboard | Flush mounted membrane keyboard with button mouse, allows full wash down and prevents build up of debris between keys |
| Shatterproof poly carbonate window | Durable screen protection without the risk of contamination of your production line in the event of breakage |
| Water repellent seals | Fitted as standard to the door, locks and window prevent damage to the enclosed equipment by ingress of liquids and allows light or heavy wash down of the enclosure |
| Slimline Construction | Easy Installation in areas where space is of concern |
| Fits most slim-line desktop, tower PC or thin client computers and TFT monitors | Add the computer of your choice saving you money on buying expensive dedicated machines |
| Surge protected four way mains distribution | Prevents damage to enclosed equipment from 'spikes' of of electricity extending life span. |
| Internal fan(s) | Maintain a stable, uniform internal temperature reducing strain on all enclosed components and extending life span |
For full specifications & prices - Contact Us Now!
Specifications & Guarantees:
All Armagard enclosures are constructed in accordance with European IP and International NEMA standards, guaranteeing protection from liquids and particulates.
- Height:
- 800mm
- Width
- 600mm
- Depth:
- 550mm
- IP rating:
- IP65
- Product Code:
- AZ2S21-TFT-UK
Specifications:
- 5 Year Warranty of all mechanical parts
- Fast delivery
- Informed and helpful staff
- High quality engineering
- Over 14 years of industry experience
